Docker Build Stages & Targets

The celeryviz Dockerfile uses a multi-stage build process to optimize image size and provide flexibility in how the application and its frontend are built.

Overview of Build Stages

The build process is divided into three main flows:

  1. Building from source: Compiling the Flutter web application from given source.

  2. Using prebuilt Frontend: Downloading a pre-compiled version of the frontend.

  3. Setting up Celeryviz: Setting up the Python application and dependencies.

Final Build Targets

  1. celeryviz: To build the docker image with prebuilt frontend.

  2. celeryviz-with-frontend-build: To build the docker image with frontend compiles from source.

  3. webapp-prebuilt: To populate the celeryviz/static folder with latest prebuilt frontend. (To be used for development)

  4. webapp-build: To populate the celeryviz/static folder with frontend built from source. (To be used for development)

Custom Build Arguments:

  • --build-arg SOURCE: Specify a different branch, tag, or commit hash.

  • --build-arg GIT_REPO: Specify a different repository URL (e.g., your own fork).

These build arguments will take effect for the build stages celeryviz-with-frontend-build and webapp-build.

Build Stages Dependency Graph

Build Stages Dependency Graph

Example: Building from a specific feature branch

  • Build the docker image with frontend compiled from source

docker build --target celeryviz-with-frontend-build \
    --build-arg SOURCE="feature/new-ui" \
    --build-arg GIT_REPO="https://github.com/your-username/celeryviz_with_lib.git" \
    -t celeryviz:custom .

  • Compile your own frontend and populate the celeryviz/static folder.

docker build --target webapp-build \
    --build-arg SOURCE="feature/new-ui" \
    --build-arg GIT_REPO="https://github.com/your-username/celeryviz_with_lib.git" \
    --output . .
